Activate the small-sliding tracking approach for interactions in Abaqus/Standard.
For Abaqus/Explicit create crush trigger assignments and surface friction assignments For Abaqus/Standard create surface beam smoothing assignments and surface vertex criteria assignments.
Create new types of surface property assignments. Similarly select materials for surface thickness assignments, surface offset assignments, and surface feature edge criteria assignments Directly select materials in addition to surfaces for the contact pairs when editing individual contact property assignments. Indicate that user subroutine VUMAT contains the effective modulus for an Abaqus/Explicit analysis and specify the hybrid formulation for hybrid elements in an Abaqus/Standard analysis for the user material model. Select the Bingham plastic or Herschel-Bulkley type to specify how you want to define the flow parameters for the gap flow model. Scale the yield stress and include the static recovery term with the nonlinear isotropic/kinematic hardening model for the plastic model. Specify the time type (total or creep) and the power and time power laws for the Drucker-Prager creep model. Specify the time type (total or creep) and the Anand, Darveaux, double power, power, and time power laws for the viscous model. Specify the time type (total or creep) and the power and time power laws for the cap plasticity model. Specify the time type (total or creep) and the Anand, Darveaux, and double power laws for the creep model. Create gap conductance, gap radiation, and gap convection material behaviors.
The Section Manager features a Material column to easily identify the materials associated with each section.Several enhancements are available for the SOLIDWORKS Associative Interface for Abaqus/CAE.Specify intersection only in the submodel boundary condition for node-based submodeling, so that Abaqus ignores driven nodes found to lie outside the region of elements of the global model.Use an analytical field to specify the thickness of individual plies in the composite layup editor.Specify multiple directory locations in the Abaqus plugin_central_dir environment file parameter rather than just a single path.Directly import CATIA V5 files as parts on the Linux platform.This post provides an overview of the new key features of Abaqus 2021 (available in FD03 (FP.2042)), Isight 2021, Tosca 2021 and fe-safe 2021.
